Components and accessories
| TFT panel elements, 6.4" - 55" |
 |
LG.Philips LCD, TFT panels
Alpha Point also supplies OEM-customers with TFT panel elements. With years of experience we've used LG (Philips) TFT panels. We offer the following models:
Click on product code for full technical specifications
Model |
Display size |
Resolution |
Brightness (cd/m²) |
Contrast |
Viewing angle (hor. º/ ver. º) |
Connector |
| LB064V02-A1, 674K |
6.4" |
VGA |
250 |
300 |
90/50 |
TTL, LG 30-pin |
| LB104V03-A1, 1.0M |
10.4" |
VGA |
400 |
300 |
120/90 (min) |
TTL, Hirose 41-pin |
| LP104S5, 535K |
10.4" |
SVGA |
170 |
200 |
80/40 (min) |
TTL, JAE 30-pin |
| LB121S02, 458K |
12.1" |
SVGA |
300 |
200 |
120/95 |
TTL, Hirose 41-pin |
| LC151X01, 489K |
15.1" |
XGA |
400 |
350 |
120/90 |
LVDS, Hirose 20-pin |
| LM151X4-A3, 794K |
15.1" |
XGA |
250 |
300 |
150/115 |
TTL, Hirose 41-pin |
| LM151X05, 363K |
15.1" |
XGA |
200 |
300 |
150/115 |
TTL, Hirose 41-pin |
| LM181E05, 636K |
18.1" |
SXGA |
250 |
350 |
160/160 |
LVDS, Molex 30-pin |
| LC201V02, 893K |
20.1" |
VGA |
450 |
400 |
170/170 |
TTL, Hirose 41-pin |
| LM201U02, 819K |
20.1" |
UXGA |
250 |
350 |
160/160 (min) |
TMDS, JAE 21-pin |
| LC230W01, 864K |
23" |
W-XGA |
450 |
400 |
170/170 |
LVDS, Hirose 20-pin |
| LC300W01, 473K |
30" |
W-XGA |
450 |
350 |
170/170 |
LVDS, Hirose 20-pin |
| LC320W02, 1.0M |
32" |
1366x768 |
500 |
600 |
176/176 |
LVDS |
| LC420W02, 834K |
42" |
1366x768 |
500 |
400 |
176/176 |
LVDS |
| LC550W01, 1.0M |
55" |
1920x1080 |
500 |
550 (1200) |
176/176 |
LVDS |
Alpha Point Ltd. holds the right for technical changes with out prior notice
|
